High Performance Single-Sided Gray Silicone Coated Fabric 3732-500

3732 Single-Sided Gray Silicone Fabric is a premium composite textile engineered for rigorous industrial and commercial environments. Featuring a high-strength base substrate uniformly impregnated and coated with advanced silicone resin on one side, this material delivers exceptional flame retardancy (Class A2), superior thermal stability, and outstanding mechanical durability. With a precisely controlled finished weight of 506.5 g/m² and a warp tensile strength exceeding 1980 N/25mm, it maintains structural integrity under heavy stress and extreme temperature fluctuations. Its smooth, defect-free surface ensures reliable dielectric properties, weather resistance, and seamless integration into demanding sealing, insulation, and safety applications.

Basic Info.

Model NO.	3732-500	Temper	Soft
Treatment	Single-Sided Silicone Coating	Thickness	0.39 mm
Surface State	Smooth Gray (Single-sided)	Rolling Characteristics	Wound on Core
Material	Reinforced Base Fabric + Silicone Composite	Sample	Available Upon Request
Finished Weight	506.5 g/m²	Base Fabric Weight	421.6 g/m²
Silicone Content	84.9 g/m² (~16.8%)	Warp Tensile Strength	1982.1 N/25mm
Total Thickness	0.39 mm	Density	Standard Reinforcement
Flame Retardancy	Class A2	OEM Customization	Width & Thickness Can Be Customized
Transport Package	Roll Packing	Specification	As Per Requirement
Trademark	Mingchen New Materials	Origin	China
Inspection Standard	JC/T170-2012 & GB/T7689.5-2013	Production Capacity	Negotiable

Application Fields

High-temperature expansion joints & flexible connections

Fireproof blankets, curtains & welding protection mats

Industrial machinery thermal insulation & sound dampening

Protective gear, gloves & apron backings

Piping wraps & aerospace component shielding

Product Features

Our Core Strengths

Delivering precision-engineered silicone composite fabrics for critical thermal and safety applications.

Exceptional Flame Resistance

Certified to Class A2 fire retardant standards, this fabric effectively resists ignition and prevents flame spread without melting, dripping, or emitting hazardous smoke, ensuring maximum workplace safety.

Superior Tensile Strength

Engineered with a reinforced carrier matrix, achieving a warp tensile strength of 1982.1 N/25mm. Resists tearing, stretching, and structural deformation under heavy loads and continuous mechanical stress.

Precision Single-Side Coating

Utilizes a uniform impregnation process applied to one side only, delivering a smooth, consistent finish with optimized dielectric properties and enhanced adhesion for secondary processing.

Strict Quality Assurance

Manufactured under rigorous testing protocols (JC/T170-2012 & GB/T7689.5-2013), guaranteeing exact thickness (0.39±0.02mm) and basis weight stability for predictable performance.

Versatile Industrial Fit

Ideal for sealing, insulating, and protecting components across HVAC, automotive, chemical processing, and construction sectors where heat dissipation and fire safety are paramount.

Packaging & Shipping

Parameter	Content
Packing	Waterproof plastic wrap + core tube + outer carton/pallet
Carton size	Customized according to roll diameter & width
Weight	Determined by customer specification
MOQ	Based on production scheduling
Lead Time	7-20 (days) depending on order volume
